1310
MC
power: | |
---|---|
Working Size: | |
Availability: | |
Quantity: | |
Product Description
It’s also called separated type stone laser engraving machine. We developed this type machine for convenience of our customers demands for heavy stone carvings. For some heavy duty stone. We can put the upper part onto them directly, so that avoiding the difficulty of moving heavy material, meanwhile, it solves the problem that platform has a limited bearing ability. Both parts can be up and down so that engraving objects with greatly thickness changing is much easier to process.
Marble, granite, tombstone, wood, acrylic, organic glass, crystal, fabric, paper, leather, rubber, ceramic,
glass and other non-metal materials, etc
1. Stone Industry(engrave ): marble, granite, white marble etc.
2. Art crafts Industry: wood, bamboo, elephant's tusk, bone, leather, marble, sea shell etc.
3. Advertisement Industry: double color board, acrylic, label, crystal etc.
4. Model Industry: sand table construction model, plane model etc.
5. Packing Industry: rubber, plastic, double-color plate, die board cutting etc.
Specifications
Laser Type | sealed CO2 glass laser tube, water-cooled,10.6um |
Cooling Type | Water cooling |
Working Speed | 0-400mm/s |
Driving System | Stepper Motor and lead shine driver |
Transmission | Chinese best FULONG Belt and Taiwan HIWIN Guide rail |
Lens and mirrors | Imported for Singapore |
Auxiliary Parts | Up-down Worktable, CW3000 Water Chiller, Air pump, Exhaust fans with air pipe |
Control system | RD with offline control system(USB/U-disk) |
Laser Output Control | 1-100% Software Setting |
Min Shaping Character | English: 1.0*1.0 mm; Chinese: 2.0*2.0mm |
Scanning Precision | 1000DPI |
Power Supply | AC 110-220V±10%, 50-60Hz |
Operating Temperature | 0°-45°C |
Operating Humidity | 5%-95% |
Locating Precision | ≤±0.01mm |
Supported File Format | DST, PLT, BMP, DXF, AI |
Compatible Software | CORELDRAW, PHOTOSHOP, AUTOCAD |
Details
Samples
